Cube Walker

📁 File Architecture

Cube Walker is built with a modular JavaScript architecture. The codebase is split across multiple files for maintainability, with each file responsible for a specific domain.

JavaScript Files

app.js Main application - game loop, core systems, Three.js scene, multiplayer, all game logic ~10,400 lines

units.js Unit classes, mesh types, unit state factory, team color helpers ~174 lines

ui.js Health bars, tile markers, move counters, route preview, overlays, victory/defeat screens ~839 lines

pure.js Pure utility functions with no side effects (stringify, easing, tile keys, MP ID generation) ~76 lines

dom.js DOM manipulation for multiplayer debug overlay (state-free DOM updates) ~220 lines

contextmenu.js Context menu system for unit interactions (healer healing, wizard cube creation) ~155 lines

cosmetics.js Decorative elements - grass, flowers, bushes placed at tile corners ~250 lines

altcubes.js Alternative cube meshes - trees and rocks that replace building cubes visually ~140 lines

Data Files

levels.json Level configurations - cube size, unit spawns, building cubes, items, merchant positions ~317 lines

index.html Entry point - loads Three.js, all modules, contains game container HTML ~166 lines

styles.css All CSS - UI elements, overlays, dialogs, merchant UI, fullscreen handling ~2,061 lines

Module Load Order

Modules must be loaded in dependency order. The index.html loads them as follows:

<!-- External Dependencies -->
<script src="https://cdnjs.cloudflare.com/ajax/libs/three.js/r128/three.min.js"></script>

<!-- Pure Utilities (no dependencies) -->
<script src="pure.js"></script>

<!-- Unit Definitions (no dependencies) -->
<script src="units.js"></script>

<!-- UI Components (depends on Three.js) -->
<script src="ui.js"></script>
<script src="contextmenu.js"></script>

<!-- DOM Utilities (depends on pure.js) -->
<script src="dom.js"></script>

<!-- Visual Enhancements (depends on Three.js) -->
<script src="altcubes.js"></script>
<script src="cosmetics.js"></script>

<!-- Main Application (depends on all above) -->
<script src="app.js"></script>


Module Dependency Graph

graph TD THREE[Three.js r128] --> app.js THREE --> ui.js THREE --> cosmetics.js THREE --> altcubes.js pure.js --> dom.js pure.js --> app.js units.js --> app.js ui.js --> app.js contextmenu.js --> app.js dom.js --> app.js cosmetics.js --> app.js altcubes.js --> app.js levels.json -.->|fetch| app.js style app.js fill:#3399ff,color:#fff,stroke:#1a1a1a style THREE fill:#1a1a1a,color:#fff style levels.json fill:#f5f0e6,stroke:#1a1a1a

🧩 Module Breakdown

units.js — Unit Definitions

Exports window.UnitModule with unit class definitions and factory functions.

Export	Purpose
`UnitClasses`	Enum of class objects (WIZARD, ROGUE, TANK, HEALER) with ability flags: `canWalkOnCubes`, `canPushCubes`, `canShootProjectiles`, `canMeleeAttack`, `canCreateCubes`, `canHealAllies`
`UnitMeshTypes`	Visual appearance types: HEDGEY_WIZARD, MOUSE_WIZARD, ROGUE_PIG, RIZARD_ROGUE, BOARBARIAN, APE_TANK, MEDICAT
`createUnitState()`	Factory function to create unit entity objects with position, HP, navigation state, timers
`getUnitTeamColor()`	Returns hex color based on unit's class and team affiliation
`isOnBlueTeam()`	Team membership check helper

ui.js — UI Components

Exports window.UIModule with Three.js-based UI elements that float above units.

Category	Functions
Health Bars	`createHealthBar()`, `createHealthBars()`, `updateHealthBars()`
Tile Markers	`createTileMarker()`, `createTileMarkers()`, `updateTileMarkers()`
Move Counters	`createMoveCounter()`, `createMoveCounters()`, `updateMoveCounters()`
Route Preview	`createRouteMarker()`, `ensureRouteMarkers()`, `updateRoutePreview()`, `clearRoutePreview()`
Selection	`createSelectionAura()`, `updateSelectionAura()`
Destinations	`updateDestinationMarker()`, `createMultiDestinationMarker()`
Move Range	`showMoveRangeOverlays()`, `updateMoveRangeOverlays()`, `clearMoveRangeOverlays()`
Overlays	`showLevelTransition()`, `showYourTurnOverlay()`, `showVictoryScreen()`

pure.js — Pure Utilities

Exports window.Pure with side-effect-free helper functions.

Function	Purpose
`safeStringify(arg)`	JSON stringify with circular reference protection for debug logging
`easeInOutQuad(t)`	Smooth animation easing curve (0→1 input/output)
`tileKey(face, u, v)`	Create consistent string key for tile lookup: `"+Z\|0\|1"`
`parseTileKey(key)`	Parse tile key back to `{face, u, v}` object
`generateMpGameId()`	Generate unique multiplayer game ID starting with "cw"

dom.js — DOM Manipulation

Exports window.DOM with multiplayer debug overlay functions.

Function	Purpose
`setMpState(state)`	Update internal MP state from app.js (connection status, game ID, etc.)
`mpDebugLog(level, ...args)`	Log to debug overlay with timestamp and level (log/warn/error)
`setupMpDebugOverlay()`	Create the debug overlay DOM elements
`updateMpDebugOverlay()`	Refresh overlay with current connection status and logs

contextmenu.js — Context Menus

Exports window.ContextMenuModule for unit interaction menus.

Function	Purpose
`init()`	Create context menu DOM element
`show(x, y, options, context)`	Display menu at screen position with options array
`close()`	Hide the context menu
`setActionHandler(fn)`	Register callback for menu item selection
`isOpen()`	Check if menu is currently visible

cosmetics.js — Decorative Elements

Exports window.CosmeticElements for visual-only scene decoration.

Function	Purpose
`populate(cubeGroup, ...)`	Add grass, flowers, bushes to all cube faces
`clear(cubeGroup)`	Remove all cosmetic meshes (for level cleanup)
`createGrassClump()`	Create multi-blade grass cluster mesh
`createFlower()`	Create tiny flower with stem and petals
`createBush()`	Create clustered sphere bush mesh

altcubes.js — Alternative Cube Meshes

Exports window.AltCubes for visual variety in building cubes.

Function	Purpose
`shouldReplace()`	Random chance (50%) to replace cube with alt mesh
`getRandomType()`	Returns 'tree' or 'rock' randomly
`createTreeMesh()`	Create tree with trunk and foliage
`createRockMesh()`	Create rock boulder mesh
`createAltCube(face, u, v, ...)`	Create positioned alt cube for building system

⚙️ app.js Core Systems

The main app.js file contains the game engine organized into major systems. Here's a map of the key sections:

System Map (by line ranges)

System	Lines	Key Functions
Sound Effects	~38-155	`SoundManager` object with `playShoot()`, `playMelee()`, `playFlip()`, `playVictory()`, etc.
Level Config	~157-400	Constants, FACES definition, EDGE_MAP, unit creation from config
Navigation State	~401-450	Global `navigation` object (System A), debug flags, camera watchdog
Turn-Based Mode	~466-680	Step tracking, action tracking, turn switching, multi-select state
Multiplayer (GunDB)	~475-650, 2569-3500	`initGunDB()`, `exportMultiplayerSnapshot()`, `applyMultiplayerSnapshot()`
Level Complete Dialog	~584-620, 1230-2000	`startLevelCompleteSequence()`, dialog balloon system, gather animations
Character Control	~667-850	`switchCharacter()`, `updateSwitchButtonState()`, selection aura
Three.js Setup	~921-990	Scene, camera, renderer, cubeGroup initialization
Init & Loading	~2185-2250	`init()` - loads levels.json, textures, creates scene, starts animate loop
Fullscreen/Landscape	~2259-2425	`setupFullscreen()`, `setupLandscapeMode()`
Projectile System	~3717-4185	`createProjectile()`, `updateProjectiles()`, damage dealing
Movement Range BFS	~4187-4400	`computeReachableTiles()`, BFS pathfinding within movement limit
Item System	~4509-4800	`createRandomItems()`, `updateItems()`, coin/book/potion collection
Merchant System	~4934-5630	`createMerchant()`, `updateMerchant()`, dialog UI, NAI merchant
Unit Updates	~5630-6200	`updateUnit()` - AI navigation, edge handling (System B)
Controlled Unit	~6195-6500	`updatePlayerControlledUnit()` - hop animation, System A navigation
Melee/Push Actions	~6900-7000	`performMeleeAttack()`, `pushCube()`, slash effects
Mesh Updates	~6998-7070	`updateUnitMesh()` - position, rotation, bobbing, hop arc
Keyboard Movement	~7070-7200	`handleKeyboardMovement()` - WASD/arrow key input
Tile Click Handling	~7200-8000	`handleTileClick()` - raycasting, action dispatch, pathfinding
Multi-Select System	~7985-8430	`startMultiUnitNavigation()`, `pumpMultiOrders()`, order dispatcher
Camera System	~8435-8600	`updateCamera()` - smooth follow, cube-face awareness
Game Loop	~8683-8820	`animate()` - main loop, update ordering, render call
Input Setup	~8820-9150	Keyboard, touch, cube rotation, pinch zoom handlers
Unit Footer	~9150-9300	`createUnitFooter()`, `updateUnitFooterHP()`
CPU Turn AI	~9400-9900	`executeSingleCPUCharacterTurn()`, AI action selection

🎲 The Cube World

Cube Walker takes place on a magical cube floating in space. Units walk on all six faces of the cube, with gravity always pulling them toward the cube's center. The cube's size varies by level, from 2×2 tiles per face (Level 0) up to 7×7 tiles (Level 5+).

Face Definitions

The cube has six faces, each defined by a normal vector and local UV coordinate axes:

The Six Faces of the Cube

graph TB subgraph Cube["🎲 The Cube"] PZ["+Z (Front)"] NZ["-Z (Back)"] PX["+X (Right)"] NX["-X (Left)"] PY["+Y (Top)"] NY["-Y (Bottom)"] end PZ --> |"+u edge"| PX PZ --> |"-u edge"| NX PZ --> |"+v edge"| PY PZ --> |"-v edge"| NY style PZ fill:#4a7a4d,color:#fff style NZ fill:#8b4513,color:#fff style PX fill:#3399ff,color:#fff style NX fill:#cc6633,color:#fff style PY fill:#6666cc,color:#fff style NY fill:#996633,color:#fff

📁 app.js Lines 227-235 — FACES object definition

Tile Coordinate System

Each face has a grid of tiles. For a cube of size N:

MIN_TILE_COORD = -floor((N-1)/2)
MAX_TILE_COORD = ceil((N-1)/2)
For N=3: coords are -1, 0, 1
For N=5: coords are -2, -1, 0, 1, 2

Edge Transitions

When a unit walks off an edge, the EDGE_MAP defines which face they transition to and how their UV coordinates are remapped. This is one of the trickiest parts of the codebase!

⚠️ Edge Crossing Complexity

Edge transitions involve coordinate remapping that can be confusing. The simulateEdgeCrossing() function handles this, but bugs in the +Y/-Y face transitions have caused units to teleport to wrong positions.

📁 app.js Lines 237-303 — EDGE_MAP and updateEdgeMap()

🧭 The Two Navigation Systems

Cube Walker has TWO separate navigation systems. Understanding when each is used is critical for avoiding bugs.

🚨 Critical Architecture Note

Mixing System A and System B fields causes units to jitter, freeze, or teleport. Always use the correct system for each context!

System A: Global Navigation (Player-Controlled Unit)

Used for: The single currently-controlled unit when moving via click or keyboard.

State object: Global navigation object

Stepped by: updatePlayerControlledUnit()

const navigation = {
    isNavigating: false,
    path: [],
    currentPathIndex: 0,
    speed: 2.5,
    isHopping: false,
    hopProgress: 0,
    hopStartU, hopStartV, hopStartFace,
    hopEndU, hopEndV, hopEndFace,
    isCrossingEdge: false
};


System B: Per-Entity Navigation (AI & Multi-Select)

Used for: AI units, and when multi-select commands multiple units.

State location: Per-entity fields on the entity object

Stepped by: updateUnit() per-entity path follower

// Per-entity navigation fields
entity.isNavigating
entity.navigationPath
entity.navigationPathIndex
entity.isHopping
entity.hopStart / hopEnd / hopT


Navigation System Decision Flow

flowchart TD A[Unit Needs to Move] --> B{Is this the controlled unit?} B -->|Yes| C{Is multi-select active?} B -->|No| D[Use System B
Per-Entity Navigation] C -->|No, single unit| E[Use System A
Global navigation object] C -->|Yes, multiple units| D E --> F[updatePlayerControlledUnit] D --> G[updateUnit per-entity path] style E fill:#3399ff,color:#fff style D fill:#cc3333,color:#fff

📁 app.js Lines 1-35 — System Map documentation header
📁 app.js Lines 401-420 — Global navigation object
📁 app.js Lines 5761-6195 — updateUnit() function (System B)
📁 app.js Lines 6195-6500 — updatePlayerControlledUnit() (System A)

🔄 The Game Loop

The animate() function runs every frame and orchestrates all game updates.

Frame Update Pipeline

flowchart TB A["0) Check game mode selected"] --> B B["1) Handle keyboard input"] --> C C["1.5) Pump multi-orders dispatcher"] --> D D["2) Update all units
updateUnit() per entity"] --> E E["2.5) Check multiplayer replay"] --> F F["3) Update projectiles, items, merchants"] --> G G["4) Update UI: markers, health bars, overlays"] --> H H["5) Update camera position"] --> I I["6) Render scene"] style D fill:#ff9966,stroke:#333

Key Update Functions Called Each Frame

handleKeyboardMovement(deltaTime) — Process WASD/arrow input
pumpMultiOrders(deltaTime) — Re-issue stuck multi-select orders
updateUnit(entity, key, dt) — Per-entity AI and navigation
updatePlayerControlledUnit(entity, key, dt) — Controlled unit hopping
updateProjectiles(deltaTime) — Move projectiles, check collisions
updateItems(deltaTime) — Animate and check item pickup
updateMerchant(deltaTime) — Merchant movement and dialog triggers
updateHealthBars() — Position health bars above units
updateTileMarkers() — Update pulsing tile indicators
updateMoveCounters() — Show remaining movement in turn-based
updateRoutePreview() — Show path preview on hover
updateCamera(deltaTime) — Smooth camera follow

📁 app.js Lines 8683-8820 — animate() main loop

⚔️ Characters & Classes

Every unit in Cube Walker belongs to one of four classes that define their abilities. The mesh type determines their visual appearance, but gameplay is driven by class.

The Four Classes

Ability	🧙 Wizard	🗡️ Rogue	🛡️ Tank	💚 Healer
Walk on Cubes	✗	✓	✗	✗
Push Cubes	✗	✗	✓	✗
Shoot Projectiles	✓ (beam)	✓ (arrow)	✗	✗
Melee Attack	✗	✗	✓	✗
Create Cubes	✓ (double-click)	✗	✗	✗
Heal Allies	✗	✗	✗	✓
Movement Range	7 tiles	9 tiles	12 tiles	12 tiles

📁 units.js Lines 8-56 — UnitClasses definition

Meet the Characters

Hedgey Wizard

Wizard Class • Blue Team Default

HP:60

Attack:30

Key:hedgeyWizard

Shoot Create Cubes

Mouse Wizard

Wizard Class

HP:70

Attack:25

Key:mouseWizard

Shoot Create Cubes

Rogue Pig

Rogue Class

HP:90

Attack:20

Key:roguePig

Shoot (Arrow) Walk on Cubes

Rizard Rogue

Rogue Class

HP:90

Attack:20

Key:rizardRogue

Shoot (Arrow) Walk on Cubes

Boarbarian

Tank Class

HP:120

Attack:35

Key:boarbarian

Melee Push Cubes

Ape Tank

Tank Class

HP:120

Attack:35

Key:apeTank

Melee Push Cubes

Medicat

Healer Class

HP:80

Attack:15

Key:medicat

Heal Allies

📁 units.js Lines 59-68 — UnitMeshTypes enumeration

🗺️ Pathfinding Architecture

The game uses BFS pathfinding with special handling for cube obstacles and cross-face navigation.

Key Functions

computeReachableTiles()

BFS flood-fill from unit position up to movement limit. Returns Map of reachable tile keys to their costs.

findPathAvoidingCubes()

Cross-face navigation wrapper. Finds optimal edge to cross and chains together per-face paths.

isBlockedForEntity()

Checks if a tile is blocked considering the entity's class abilities:

function isBlockedForEntity(entity, face, u, v, entityKey) {
    if (isTileOccupiedBySprite(face, u, v, entityKey)) return true;
    if (hasBuildingCube(face, u, v) && !entity.unitClass.canWalkOnCubes) return true;
    return false;
}


Pathfinding Call Hierarchy

flowchart TD A[Player clicks tile] --> B{Same face?} B -->|Yes| C[BFS within face] B -->|No| D[findPathAvoidingCubes] D --> E[Find optimal edge crossing] E --> F[BFS to edge] E --> G[BFS from landing] F --> H[Combine paths] G --> H C --> I[Navigate path] H --> I

💡 allowCubes Parameter

All pathfinding functions accept an allowCubes boolean. This MUST be set to entity.unitClass.canWalkOnCubes for proper Rogue behavior. Forgetting this causes Rogues to path around cubes they should climb!

📁 app.js Lines 4187-4370 — computeReachableTiles() and BFS

🌐 Multiplayer Architecture

Multiplayer uses GunDB for real-time state synchronization between two players.

Connection Flow

Multiplayer Join Flow

sequenceDiagram participant Host participant GunDB participant Joiner Host->>GunDB: Create game (cwXXXX) Host->>Host: Display join URL Joiner->>GunDB: Subscribe to cwXXXX GunDB->>Joiner: Initial snapshot Joiner->>Joiner: Apply snapshot loop Each Turn Host->>GunDB: Export snapshot + end turn GunDB->>Joiner: Snapshot update Joiner->>Joiner: Apply, execute turn Joiner->>GunDB: Export snapshot + end turn GunDB->>Host: Snapshot update end

Snapshot Structure

The multiplayer snapshot contains complete game state:

{
    seq: 123,                    // Sequence number
    level: 1,                    // Current level
    isBluesTurn: true,           // Whose turn
    units: { ... },              // All unit states
    buildingCubes: [ ... ],      // Cube positions
    items: [ ... ],              // Item states
    stepsTakenThisTurn: { ... },
    actionTakenThisTurn: { ... }
}


📁 app.js Lines 2799-2850 — initGunDB()
📁 app.js Lines 3090-3145 — exportMultiplayerSnapshot()
📁 app.js Lines 3147-3385 — applyMultiplayerSnapshot()

✨ Adding New Content

Adding a New Character

Add the Mesh Type (units.js)

const UnitMeshTypes = {
    // ... existing types ...
    MY_NEW_UNIT: 'my_new_unit',
};


Add Key Mapping (units.js)

Update generateUnitKey():

const keyMap = {
    [UnitMeshTypes.MY_NEW_UNIT]: 'myNewUnit',
};


Add Texture URL (app.js)

In createAllUnits() textureUrls:

[UnitMeshTypes.MY_NEW_UNIT]: 'https://your-cdn.com/sprite.webp',

Add to Level Config (levels.json)

{
  "meshType": "MY_NEW_UNIT",
  "unitClass": "WIZARD",
  "face": "+Z",
  "u": 0, "v": 1,
  "maxHP": 80,
  "attackPower": 25
}


Adding a New Level

Add a new object to levels.json with:

cubeSize — Grid dimension (3-7 recommended)
blueTeam / redTeam — Unit spawn arrays
buildingCubes — Initial cube positions
items — Coins, books, potions
merchant / naiMerchant — Merchant positions (optional)
dialogs — Level-complete dialog lines

✅ Level Added!

New levels are automatically loaded. Update maxLevel in app.js if needed.

🐛 Known Issues & Edge Cases

Rogue Pathing on Cubes

Sometimes Rogues don't path correctly onto cube tops. Ensure allowCubes = entity.unitClass.canWalkOnCubes is passed to ALL pathfinding calls.

+Y/-Y Face Transitions

The top and bottom face edge mappings in EDGE_MAP are particularly tricky. Test thoroughly when modifying.

Multi-Select Order Persistence

Orders in multiOrders Map persist until arrival. If a unit gets stuck, the order fuse (MAX_ORDER_FAILS) will eventually clear it.

Multiplayer Snapshot Timing

Snapshots are exported after committing all movement. If a unit is mid-hop during export, commitAllMovement() snaps them to destination.

📁 diagnosis.html — Detailed bug analysis for battle freeze issues

🔧 Refactoring Recommendations

The codebase has grown organically and could benefit from these improvements:

Priority 1: Unify Navigation Systems

Current Problem

Two navigation systems (global navigation vs per-entity fields) are confusing and error-prone.

Solution: Move ALL navigation state to per-entity fields. The "controlled unit" can simply be identified by a flag, not by using a different data structure.

Priority 2: Further Module Extraction

Split the remaining 10,000+ line app.js into:

navigation.js — Pathfinding and movement
combat.js — Projectiles, damage, attacks
cube.js — Cube geometry, face transitions
multiplayer.js — GunDB sync, snapshots
merchant.js — Merchant system and dialogs

Priority 3: State Machine for Unit Behavior

Replace timer-based AI with explicit state machines:

const UnitStates = {
    IDLE: 'idle',
    MOVING: 'moving',
    ATTACKING: 'attacking',
    HOPPING: 'hopping',
    WAITING: 'waiting'
};


Priority 4: Type Annotations

Add JSDoc comments for better IDE support:

/**
 * @typedef {Object} UnitEntity
 * @property {string} face - Current face (+X, -X, etc)
 * @property {number} u - U coordinate
 * @property {number} v - V coordinate
 * @property {UnitClass} unitClass - The unit's class
 * @property {boolean} isBlueTeam - Team affiliation
 */
